Fluid Bed Dryer Machine

Product Description

• Fluid Bed Dryer (FBD)
Priyal Propack’s Fluid Bed Dryer is an efficient drying system designed for uniform drying of wet materials by suspending particles in a heated air stream. This process ensures rapid moisture removal while maintaining product integrity. Commonly used in industries such as pharmaceuticals, chemicals, and food, the dryer features components like electric heaters, pneumatic systems for lifting and sealing, and precise airflow control for optimal performance. Contact parts are made from stainless steel (SS 316) for durability and compliance with hygiene standards.

• They are design as per (a) ASME Sec VIII Div-1, Ed.2013 CGMP Guidelines.
• Process connections of tanks are as per SME BPE.

Notes:

• Batch Capacity (kg): Refers to the weight of material processed per batch, dependent on material bulk density (typically 0.5-0.75 g/cm³). Actual capacity may vary based on material properties.
• Total Volume (Liters): Volume of the product container, with working volume typically 60-70% of total volume to ensure proper fluidization.
• Blower Motor (HP): Power rating for the centrifugal blower creating the airflow for fluidization. Higher capacities require larger motors.
• Steam Consumption (kg/hr): Based on steam at 3-4 kg/cm² pressure for heating. Electric heating options (kW) may be available for smaller models.
• Heating Capacity (kCal/hr): Thermal energy required for drying, assuming inlet air temperature of 60-80°C.
• Dimensions and Weight: Approximate values for GMP-compliant models with stainless steel construction (SS 316L for contact parts, SS 304 for non-contact parts).

Operating Conditions:

• Inlet Air Temperature: Adjustable, typically 50-80°C (up to 120°C for specific applications).
• Drying Time: 20-45 minutes, depending on material moisture content and batch size.
• Air Flow Rate: 0.4-0.8 m³/min for smaller models, up to 6 m³/min for larger models.
• Features:
• Designed for drying, granulation, and coating in pharmaceutical, food, chemical, and agricultural industries.
• Complies with cGMP norms, featuring perforated air distribution plates, finger bag filters, and optional PLC-based controls.
• Safety features include explosion flaps (2-3 Bar pressure rating), earthing devices, and motor overload protection.
• Optional CIP/WIP systems, air velocity measurement, and inlet air humidity control for precise operation.
• Applications: Drying of wet granules, powders, and pellets; granulation and coating processes for pharmaceutical tablets, food products, fertilizers, and chemicals.
• Customization: Capacities and configurations (e.g., top/bottom spray systems, continuous vs. batch operation) can be tailored to specific requirements.
• Specifications are indicative and may vary by manufacturer. Always consult the equipment supplier for precise details and custom configurations.
• Advanced controls, Energy-efficient, high airflow, fast drying. Order now!
